Optional CF Pod Plate for you SE Gen3 Kit.  This CF piece will shed about 3g of weight and it will increase rotation of your car.  Recommended for stock classes.

IN STOCK!

RX28D Gen 3 – 1/28 Scale RC Car Chassis Kit

Redefine Performance. Precision. Possibility.

The RX28D Gen 3 is here to raise the bar for 1/28-scale RC racing. Built for drivers who demand speed, agility, and pinpoint control, this third-generation chassis is fully re-engineered to dominate the track with cutting-edge design and next-level adjustability.

🔧 Key Upgrades & Features

🚗 Front-End Enhancements:

• 1mm longer front arms for improved stability and smoother handling

• Integrated sway bar system for surgical cornering precision

• Adjustable caster (via 3 screws)

• Integrated front shock tower with shim-based ride height tuning

• Upper arm hinge pin height adjustment for custom camber gain and roll center

• Lightweight & durable plastic knuckles – new design, less weight, more strength

• Low-profile big bore shocks & springs – ultra-smooth, responsive handling

🏁 Rear-End Innovations:

• Lower CG Rear End for high-speed stability

• New motor mount – lowers motor by 0.8mm

• 3-screw damper mount – simplifies rear suspension servicing

• Tweak brace lowered by 1.25mm for improved response

• Shorter side springs + thinner perches

• Side dampers lowered by 3mm, now screw-mounted to motor mount

• Smaller center shock spring, collar, and perch

• Pinned rear motor pod plate – boosts durability and rear-end precision

🛠️ Ease of Maintenance:

• Standardized ball stud hardware used throughout

• Simplifies adjustments and part replacements

• Designed with trackside tuning in mind

📦 What's Included:

• RX28D Gen 3 Chassis Kit

• One set of wheels and tires (pre-mounted)

⚠️ Note: Electronics NOT included. See below for compatibility.

📏 Specifications:

• Wheelbase: 98mm

• Weight (RTR): 145g–170g (depending on body & electronics)

• Rear Track Width: 69mm–78mm

• Front Track Width: 72mm–75mm

🔌 Electronics Required (Not Included):

• Motor

• LiPo Battery

• ESC (Electronic Speed Controller)

• Receiver

• Servo

✅ Compatible Servos:

• Reflex Racing RRE007 (20T Spline) – Recommended

• AGFC A06CLS V1

• GL Racing Servo

• PN Anima

• Atomic Servo (tight fit, but compatible spline size)

🛠️ You Will Also Need:

• Body + Mounting Hardware

• Compatible electronics listed above

🚨 NOTE:

ELECTRONICS ARE NOT INCLUDED! This kit is designed for experienced builders who want a customizable, high-performance platform.

Presale on Restock

IN STOCK NOW!

RX28SE Gen 3 – 1/28 Scale RC Chassis Kit

Precision. Versatility. Style.

Get ready to take your racing program to the next level with the RX28SE Gen 3 — the ultimate 1/28th-scale RC car chassis designed for enthusiasts who demand performance without compromise. This third-generation platform is built to dominate any surface with fine-tuned handling, premium materials, and unmatched tuning potential.

Key Features & Upgrades

Revamped Front-End:

• 1mm longer front arms for enhanced stability

• All-new sway bar system for sharper cornering response

• Adjustable caster (3-screw system)

• Integrated front shock tower with shim adjustment

• Adjustable upper arm hinge pin height for custom camber gain and roll center tuning

• Low-profile big bore shocks & springs for buttery-smooth handling and high grip

Rear-End Innovations:

• Lower CG Rear Design for increased agility

• New motor mount – lowers motor by 0.8mm

• 3-screw damper mount – simplifies rear suspension maintenance

• Tweak brace dropped by 1.25mm for enhanced cornering performance

• Shorter side springs & thinner perches

• Side dampers lowered by 3mm, now screw-mounted to motor mount

• Smaller center shock spring, collar, and perch

• Pinned Rear Motor Pod Plate – improved precision and durability

Signature SE Upgrades:

• 24mm Steel Tub Chassis – Industry-leading rigidity, low CG, and durability

• Includes both Premium Ball Differential & Gear Differential

• Two sets of plastics included: Black & Gray (excluding lower arms)

What's Included:

• RX28SE Gen 3 Chassis Kit

• One Set of Wheels & Tires

• Steel Tub Chassis

• Ball & Gear Differential

• Black & Gray Plastic Parts (excluding lower arms)

Note: Electronics, body, and mounting hardware are NOT included.

Specifications:

• Wheelbase: 98mm

• Weight (RTR): 145g–170g (depending on body & electronics)

• Rear Track Width: 69mm–78mm

• Front Track Width: 72mm–75mm

Required to Complete (Not Included):

• Body & Mounting Hardware

• Electronics:

  • Motor

  • LiPo Battery

  • ESC (Electronic Speed Controller)

  • Receiver

  • Servo

Servo Compatibility:

• Reflex Racing RRE007 (20T Spline) – Recommended

• AGFC A06CLS V1

• GL Racing Servo

• PN Anima

• Atomic Servo (tight fit, but correct spline size)

Important Notes:

• ELECTRONICS ARE NOT INCLUDED

Low Profile Damper System – PN2.5 AAA Chassis

Achieve the Ultimate Low CG Setup for Your AAA Car

Introducing our all-new Low Profile Damper System, specially engineered for the PN2.5 AAA chassis. By repositioning the dampers through innovative design, we've created an extremely low center of gravity suspension setup—delivering unmatched performance and handling on the track.

This high-performance suspension kit is designed for simplicity and compatibility, making it easy to upgrade your PN2.5 with confidence.

Key Features:

• ✅ Ultra-Low CG Design – Improved cornering stability and smoother transitions

• ✅ Direct Fit for PN2.5 AAA Chassis – No modification needed

• ✅ T-Bar Compatible – Seamlessly integrates with traditional T-bar setups

• ✅ Durable & Lightweight – Engineered for serious racers

What’s Included:

• Complete Low Profile Damper Assembly

• All required mounting hardware

• Instructions for easy installation

Note: Center top shock is not included. You can use our Reflex Racing RX28A-32 or any other traditional 1/28 scale center shock of your choice.

Upgrade your suspension. Lower your CG. Win more races.

Introducing the Reflex Racing TRUE SPEC 460mAh Battery
All-new from Reflex Racing, the True Spec 460mAh LiPo delivers increased capacity, significantly lower internal resistance, and a flatter discharge curve—all in the same footprint as our popular 400mAh 8.7V LiHV pack. At only 13.0mm tall (vs. 12.3mm on the 400mAh), this pack offers approximately 30% lower IR, resulting in improved performance and reduced fade.

Dimensions: 44.8 × 24.0 × 13.0 mm

Perfect for Stock and Super Stock racing, where holding power throughout the run is critical.

Reflex Racing Battery Lineup

RRE012 – 340mAh LiHV

• Ideal for general hobby use

• Fits most platforms

• Great for drifting and home tracks

• Best when power demands are moderate

RRE015 – 400mAh LiHV

• Excellent for Modified racing

• Ideal for shorter tracks

• Offers slightly lower CG

• Smoother power response

• Preferred when lower CG matters more than the flatter discharge curve of the 460mAh

RRE025 – 460mAh LiPo (True Spec)

• Maximum power and runtime

• Highest capacity and lowest IR hardcase 1/28 battery on the market

• Best choice for Stock, Super Stock, and short-charge Modified racing

• Flattest discharge curve and strongest punch in the lineup

FX28-015 FX28 Steel Front Axles

Reverse Titanium Axles V2 – Adjustable Trackwidth System

Upgrade your front end with our V2 Reverse Axles, now machined from titanium for improved durability and long-lasting performance. These axles allow you to fine-tune your front offset by 1mm, adjustable in 0.5mm increments using the included M3 x 0.5mm axle shims.

Compatibility

• Reflex Racing RX28

• GL Racing chassis

• Atomic chassis

Why Reverse Thread?

By reversing the thread direction and using a screw instead of a nut, the axle system greatly reduces the chance of your front wheels snagging on RCP rails, especially when running low-offset wheels.

What’s Included

• 2× Titanium Reverse Axles (V2)

• 4× M3 x 0.5mm Copper Shims

• 2× M2 × 4mm Button Head Screws

Pro Tip

Depending on the wheels used, there may be a small amount of axial side-to-side play.
To eliminate this, you can lightly sand the outer axle surface to reduce the width slightly.

When the V3 Tool Set Came out we were still setting our style. We made sure we made the tool sets really good quality, but we were still using slightly customized, generic handles offered by tool factories. This time around though, we designed our own tools from the ground up. Careful attention was placed on the details and the result is a super nice tool set that now matches all you other cool Reflex Tools.

All new from Reflex Racing is out 2WD Solid Axle Set.  This direct drive axle is recommended for slower classes like 3500 AAA, F1 and GT 2500 LiPo.  The Solid axle is super light weight and provides superior acceleration and on power steering over a ball or gear diff.  We suggest using this in high bite conditions and larger tracks.

FX28A-16 FX28 Center Spring - Gray (Super Soft)

FX28A-15 FX28 Center Spring - Light Blue (Ultra Soft)

Use this ball reamer on your pivots on you Reflex Cars to get super smooth movement.
