EasyLap Micro Transponder with Blue Case, Power Wire and Connectors

The EasyLap Micro is an ultra-compact infrared transponder built for the smallest RC classes where space and weight are at a premium. Measuring just 10 x 9 x 4mm, it installs in minutes and sits low enough to virtually disappear on the car. Compatible with EasyLap and Robitronic lap counter systems.

The transponder slides out of its blue case and fits any compatible colored case, making it easy to match your livery or identify your car on track. Includes ESC power wire with 2, 3, and 4 prong connectors for broad compatibility.

Mounting Note: For reliable lap detection, mount the transponder with the IR sensor facing directly upward toward your timing system.

Specifications

• Dimensions: 10mm (H) x 9mm (W) x 4mm (D)
• Compatible systems: EasyLap, Robitronic
• Includes: Blue case, ESC power wire with 2, 3, and 4 prong connectors
• Part Number: EZ001X

EASYLAP MiniZ RWD Transponder Connector Cable (For Kyosho Mini-Z)

A dedicated plug-and-play connector cable for integrating an EASYLAP transponder directly into the Kyosho Mini-Z RWD chassis. No soldering required — connects to the receiver board or battery posts on the chassis for a clean, reliable installation.

Compatible with EASYLAP timing systems and designed specifically for Kyosho Mini-Z RWD models.

Specifications

• • Part Number: ET009-S
  • Compatibility: Kyosho Mini-Z RWD
  • Includes: (1) Transponder connector cable

EasyLap Timing Bridge Sensor Module — ET002 0.3m Cable

The ET002 Timing Bridge Sensor Module is EasyLap's dedicated detection module for use at the timing bridge. Compact and straightforward to install, it delivers the consistent, accurate transponder detection your race program depends on — whether you're running a permanent track setup or packing up for a race day away from home.

The included 0.3m cable keeps your bridge installation clean and tidy without unnecessary cable run.

Please Note: The ET002 is an add-on sensor module and is not a standalone timing solution. Operation requires the EasyLap EZL02 main module (or equivalent) and EasyLap timing software.

Features:

• Add-on timing bridge sensor module
• Consistent, reliable transponder detection
• Compact, low-profile design
• Easy bridge mounting and installation
• 0.3m connection cable included
• Suitable for permanent and portable track setups

Requirements:

• EasyLap EZL02 main module or equivalent
• EasyLap timing software

Part Number: ET002

EasyLap Personal Transponder

Compact, lightweight, and ready to race straight out of the box. The EasyLap personal transponder comes housed in a blue case and installs easily onto your car in minutes. Its small profile keeps weight and bulk to a minimum — ideal for 1/28 scale and other mini RC classes where every gram counts.

Need a different look? The transponder can be removed from its case and swapped into any compatible colored case to match your style or help identify your car on track.

Mounting Note: For reliable lap detection, mount the transponder with the IR sensor facing directly upward toward your lap counting system.

Features:

• Compatible with EasyLap and Robitronic lap counter systems
• Compact low-profile design: 13mm (H) x 12mm (W) x 5mm (D)
• Removable case with support for colored case swaps
• Easy installation

Part Number: EZ001

EasyLap RC Lap Timing System — EZL02 USB Interface with Transponders

The EZL02 is EasyLap's complete plug-and-play lap timing solution for RC racing. Powered directly through USB with no external power supply required, the EZL02 is ready to run straight out of the box — just connect, install the free software, and start racing.

Designed for both indoor and outdoor tracks, the EZL02 supports unlimited cars via compact personal transponders, making it equally at home at a casual club night or a full race day event. The included multilanguage race software handles everything from practice sessions to full race day management.

What's in the Box:

• EZL02 USB main module
• 4 x IR sensors
• Sensor cable
• USB adapter cable
• 4 x personal transponders

Features:

• USB powered — no external power supply required
• Supports unlimited cars
• Compact personal transponders for easy car mounting
• Free multilanguage race management software included
• Suitable for indoor and outdoor track use
• Expandable with additional sensor modules (ET002)

Part Number: EZL02

Swave-E2-W Motor Sensor Cable

BLUETH2

ENSO BLUETH-2 designed or IOS user, easily and remotely access your ESC to change the parameter and firmware update wirelessly, also telemetry monitors the battery voltage / ESC temperature/throttle and motor rpm, without leaving the driver to stand.

An advantage of the unbelievable micro size you can place it anywhere inside the car.

Each Bluetooth adaptor has its unique ID and password, prevent to mess up with other drivers' phones.

* Micro Size

* Low energy Bluetooth

* Wireless setting

* Wireless firmware update

* Telemetry monitor the battery voltage / ESC temperature / throttle / rpm

Support ESC: Swave-E2 / Swave-W / Swave-W2 (doesn't support Swave-E)

System Support: iPhone 7 or later / IPAD Pro or later

PCB Size: 1cm*1cm (exclude cables)

Different to use Android version "ENSO BLUETH" and IOS version ENSO BLUETH-2 on IOS device;

IOS has its own password protocol then the Android, if use Android version "ENSO BLUETH" on IOS device although there is no problem if you are the first time to establish the connection, if trying to reconnect again it’s prohibited by IOS system, you have to remove the "ENSO BLUETH" from the phone system then go back to Swave apps to search your "ENSO BLUETH" and input password again like you are the first time to establish the connection. To use ENSO BLUETH-2 is no longer repeating the process.

ENSO BLUETH-2 may communicate with some Android devices but Ensotech cannot guarantee and we cannot make its work on all kinds of Androids. If you are using Android device please purchase the Android version - ENSO BLUETH

About IOS Swave apps

Swave Apps IOS final version is still under development. This beat version is available under the apple "test flight" program. This is a developer program that allows users to test the apps for developers. Please note this beat version is still at the elementary level, it doesn't have the full features compare to the Android version, an example it doesn't have the “power switch mode” features. If you are interested to use the apps please email your Apple ID email address to us info@ensotech.com. You will receive an invitation email within 24 hours Monday to Friday request to download the Apple "Test Flight apps" from Apple App Store, after installed there is a Swave apps icon inside the test flight apps, click the icon to download the Swave app from App Store then start to use. During the process will require to do the registration.

Swave-W2 Sensored Electronic Speed Controller makes technology essential to your modern mini R/C car.

The principle of W2 to enhance heating dissipation. Used high watts thermal PAD, more copper inside PCB for current flow optimization, and the length of PCB increased 1mm compared to W.

Besides, the schematic has also been re-engineered to improved control of Bluetooth power..... ready for future gadget tech.

Ideally to use on microscale 1:28 RWD and shaft drive AWD touring car who needs liner and responsiveness on drifting and touring race. Enjoy the best value versus performance ratio, size, weight, technology as well as other advantages.

Features

"Blinky-mode" provides a fair racing environment between racers. (Shows that all timing advance switched to zero)

Stunning size and weight

Easy-to-use programming

Firmware update available

A professional set of customized parameters for the difficult race track

Automatic recognition of Hall sensor’s position

Settings configurations export and import. (You can save and load configuration or share out)

Aluminum body

Firmware update and change setting via Android version swave apps

Optional UARTLINK-II programming cable

Optional wireless EnsoBlueth Bluetooth adaptor

Optional power connector to battery (JST-PH) OR (MR-30 male) + (MR-30 Female)

Specification:

* Dimensions (mm): 26.00(L)*13.20(W)*7.86(H)

* Weight: 4.5g

* Supply Voltage: 2s LiPo / 2s LiOn

* Const./Brust Current (A): 20/30A (under 90 degree Celsius)

* Sensor input: 1 (5 pins)

* Programming input: 1

* Receive input: 1

* Support motor type (Sensored): Slotless 15mm Brushless DC up to 7500kv

* Support motor type (Sensorless): Slotless 15mm Brushless DC

* BEC Output: 5V / 1.5A

Package Included:

1* Swave-W2 ESC

1* Receiver Cable (JST)

1* Receiver Cable (JR)

1* Motor Sensor Cable (product code: CABLE06)

Motor Compliance:

The Swave series of electronic speed controllers (ESC) uses a very unique, groundbreaking, and revolutionary patented technology, which only Ensotech masters. This precision technology requires a very careful and specific engineering process for sensored motors and demands the use of high-quality motor components (i.e. sensor, PCB, stator, winding, etc..) coupled with the accuracy of the motor’s build and timing ‘tuning’. Ensotech certified motors meet all the manufacturing and quality control criteria imposed by Ensotech and would guarantee the best performance of your Swave series ESC. The use of non-Ensotech certified motors shall immediately void the Ensotech warranty.

Ensotech does not impose any restrictions on the use of sensorless 1528 sized brushless motor with the Swave series ESC.
